Galvanized Chain DIN 5684

Our chain DIN 5684 is a kind of welded fine tolerance hoist chain meeting the requirements of DIN 5684. The chain is grade T (types T, DAT, DT), which comply with the requirements of DIN EN 818-7. Excepting type DAT and type DT chains, other grade T chains are not only suitable for chain hoists, but also other lifting equipment.

We are able to supply DIN 5684 chain with diameter range from 4 mm to 22 mm. Available packages are in hanks, reels, drums, bags or as your request.

Usage of different types of Chain DIN 5684

• T type -- suitable for hand chain hoist or low-speed power-driven link chain hoist without consideration of wear

• DAT type -- suitable for heavy-duty high-speed power-driven link chain hoist

• DT type -- suitable for power-driven link chain hoist under wear condition

We are also able to supply fine tolerance hoist chains in accordance with Chinese Standard GB/T 20947. Please contact us for more information.

Features of Chain DIN 5684

• Specification: DIN 5684

• Fine tolerance

• Types: grade T (types T, DAT, DT)

• Finishes: natural color, electrogalvanized, hot dip galvanized

• Applications: lifting purposes

Specifications of Chain DIN 5684

Packing & Delivery
