Type A Malleable Drop Forged Cable Clamps For Lifting 6mm To 50mm

Type A Malleable Drop Forged Cable Clamps For Lifting 6mm To 50mm
Type A Malleable Drop Forged Cable Clamps For Lifting 6mm To 50mm
Type A Malleable Drop Forged Cable Clamps For Lifting 6mm To 50mm Type A Malleable Drop Forged Cable Clamps For Lifting 6mm To 50mm Type A Malleable Drop Forged Cable Clamps For Lifting 6mm To 50mm

Large Image :  Type A Malleable Drop Forged Cable Clamps For Lifting 6mm To 50mm

Product Details:
Place of Origin: CHINA
Brand Name: LKY
Certification: CE, ISO
Model Number: Type A Malleable Wire Rope Clip
Payment & Shipping Terms:
Minimum Order Quantity: 1 ton
Price: Negotiable
Packaging Details: Carton + Pallet
Delivery Time: 60 days
Payment Terms: T/T
Supply Ability: 200 tons per month
Contact Now

Type A Malleable Drop Forged Cable Clamps For Lifting 6mm To 50mm

Description
Product Name: Type A Malleable Wire Rope Clip Material: Malleable
Surface: Galvanized Size: M6 - M50
Weight: 0.03 - 4.8 Kg/pc Packing: Cartong + Pallet
High Light:

drop forged cable clamps 6mm

,

drop forged cable clamps 50mm

,

Type A cable clamps for lifting

Carbon Steel Type A Galvanized Malleable Wire Rope Clip

Type A Galvanized Malleable Wire Rope Clip:

Our company is specialized in rigging hardware. We have our own factory and also coorperate with other factories with high quality products. The price of our product is very competitive. And if you make business relationship with us, you will enjoy our the best service. Welcome to get in touch with us.

Details:

1. Model: Type A Galvanized Malleable Wire Rope Clip

2. Material: Steel

3. Usage: Wire Rope Clip, marine hardware,etc.

4. Surface Treatment: Electro galvanized, Hot dipped galvanized

5. Size: From 6mm to 50mm

6. Packing: Gunny bag or carton and pallet / by customer requirments

7. Our advantages: qualty assurance, experienced staff, professional service, competitive price, etc.

8. Certifications: ISO9001, CE

9. Notes: Special specifications and marks can be made according to customers requirements

Specification:



Size A B C D E F G 100/WT
mm kg
6 12 17 14 5 14 23 24 2.5
8 15 21 16 6 17 28 30 4.5
10 19 28 20 8 21 38 37 9
12 24 34 25 10 27 45 47 18
15 29 40 30 12 32 52 56 28
20 36 47 36 14 38 62 70 47
22 40 52 39 16 43 69 77 62
25 43 56 44 18 50 76 85 85
28 48 62 48 20 57 85 95 120
32 55 67 51 22 61 93 108 157
40 64 81 62 24 73 111 120 261
45 72 88 70 27 86 123 137 363
50 80 95 80 30 95 135 154 480



Type A Malleable Drop Forged Cable Clamps For Lifting 6mm To 50mm 0

Type A Malleable Drop Forged Cable Clamps For Lifting 6mm To 50mm 1Type A Malleable Drop Forged Cable Clamps For Lifting 6mm To 50mm 2



Packing & Delivery

Type A Malleable Drop Forged Cable Clamps For Lifting 6mm To 50mm 3

Type A Malleable Drop Forged Cable Clamps For Lifting 6mm To 50mm 4
