Product Details:
|
| Product Name: | Galvanized Screw Pin Chain Shackle U.S Type G210 | Material: | Carbon Steel, Alloy Steel, Stainless Steel |
|---|---|---|---|
| Surface: | Electric Galvanized, Hot Dipped Galvanized, Self-colored | Size: | From 1/4 Inch To 2-1/2 Inch |
| Packing: | Cartong + Pallet | WLL: | 1/2- 55 Tons |
| High Light: | crosby screw pin shackle G210,Galvanized crosby screw pin shackle,safety anchor shackle G210 |
||
Screw pin chain shackles US type G210 are key products in rigging systems. Our company has specialized in producing this product for many years and we also co-operated with other factories with high quality products, so the price is very competitive. We are looking forward to establising business relationship with you.
Details:
1. Model: Screw Pin Chain Shackle US Type G210
2. Material: Stainless steel, Carbon steel, Alloy steel
3. Usage: Marine hardware, electric power, machinery, metallurgy
4. Surface Treatment: Electric galvanized, hot dipped galvanized, self- colored
5. Size: From 1/4 inch to 2-1/2 inch
6. Packing: Gunny bag or carton and pallet / by customer requirments
7. Our advantages: quality assurance, experienced staff, professional service, competitive price, etc.
8. Certifications: ISO9001, CE, SGS
9. Notes: Special specifications and marks can be made according to customers requirements
Specification:
| Size | WLL | Pin dia | IL | Weight Each |
| in | tons | in | in | lbs |
| 1/4 | 1/2 | 5/16 | 7/8 | 0.11 |
| 5/16 | 3/4 | 3/8 | 1-1/32 | 0.17 |
| 3/8 | 1 | 7/16 | 1-1/4 | 0.24 |
| 7/16 | 1-1/2 | 1/2 | 1-7/16 | 0.40 |
| 1/2 | 2 | 5/8 | 1-5/8 | 0.59 |
| 5/8 | 3-1/4 | 3/4 | 2 | 1.21 |
| 3/4 | 4-3/4 | 7/8 | 2-3/8 | 2.25 |
| 7/8 | 6-1/2 | 1 | 2-13/16 | 3.16 |
| 1 | 8-1/2 | 1-1/8 | 3-3/16 | 4.47 |
| 1-1/8 | 9-1/2 | 1-1/4 | 3-9/16 | 6.75 |
| 1-1/4 | 12 | 1-3/8 | 3-15/16 | 9.06 |
| 1-3/8 | 13-1/2 | 1-1/2 | 4-3/8 | 11.60 |
| 1-1/2 | 17 | 1-3/4 | 4-13/16 | 15.95 |
| 1-3/4 | 25 | 2 | 5-3/4 | 26.75 |
| 2 | 35 | 2-1/4 | 6-3/4 | 42.31 |
| 2-1/2 | 55 | 2-3/4 | 8 | 71.75 |
Packing & Delivery
