Product Details:
|
| Product Name: | G80 Eye Grab Hook H/A 323 | Material: | High Alloy Steel Or Carbon Steel |
|---|---|---|---|
| Surface: | Hot Dip Galvanized, Zinc Plated Or Self Color | Size: | 1/4'' - 3/4'' |
| Packing: | Cartong + Pallet | WLL: | 1.2T-31.5T |
| High Light: | Alloy Steel eye grab hook,eye grab hook Zinc Plated,clevis grab hook G80 |
||
Eye grab hook H/A 323 drop forged by high quality carbon steel and alloy steel with hot dip galvanizing on the surface. It has the advantages of small volume, light weight and high strength. The maximum test load is 2 times of work load, and the minimum break load is 4 times of work load. It can be widely used in mine, large factory, shipping, metallurgy, bridge constraction and so on.
product details:
1. Item: Eye Grab Hook H/A 323
2. Type: US type
3. Grade: 80
4. Material: high alloy steel or carbon steel
5. Technology: drop forged
6. Surface: hot dip galvanized, zinc plated or self color
7. WLL: 1.2T-31.5T
8. Breaking load: 4 times of working load
9. Usage: lifting, rigging
10. Size: 1/4"mm-3/4"mm
11.Special specifications and marks can be made according to customers requirement
Specification:
| Size | N.W. | W.L.L.(LBS) | R | Φ | E | |
| IN | LBS | H-323 | A-323 | MM | MM | MM |
| 1/4' | 0.28 | 2600 | 3600 | 50.5 | 13 | 9 |
| 5/16' | 0.45 | 3900 | 5400 | 56.8 | 14 | 11.5 |
| 3/8' | 0.79 | 5400 | 7500 | 65.2 | 17 | 13 |
| 7/16' | 1.19 | 7200 | 10000 | 74.7 | 19 | 15.5 |
| 1/2' | 1.8 | 9200 | 12750 | 85.5 | 22 | 17 |
| 5/8' | 3.3 | 12750 | 19000 | 116 | 30 | 21 |
| 3/4' | 6 | 18500 | 27000 | 133.5 | 35 | 25 |
