Galvanized M56 Turn Buckle Self Color Carbon Steel DIN1480 Turnbuckle

Certification
China HUIXING INDUSTRY (QINGDAO) CO.,LTD. certification
China HUIXING INDUSTRY (QINGDAO) CO.,LTD. certification
I'm Online Chat Now

Galvanized M56 Turn Buckle Self Color Carbon Steel DIN1480 Turnbuckle

Galvanized M56 Turn Buckle Self Color Carbon Steel DIN1480 Turnbuckle
Galvanized M56 Turn Buckle Self Color Carbon Steel DIN1480 Turnbuckle
Galvanized M56 Turn Buckle Self Color Carbon Steel DIN1480 Turnbuckle Galvanized M56 Turn Buckle Self Color Carbon Steel DIN1480 Turnbuckle Galvanized M56 Turn Buckle Self Color Carbon Steel DIN1480 Turnbuckle Galvanized M56 Turn Buckle Self Color Carbon Steel DIN1480 Turnbuckle Galvanized M56 Turn Buckle Self Color Carbon Steel DIN1480 Turnbuckle Galvanized M56 Turn Buckle Self Color Carbon Steel DIN1480 Turnbuckle Galvanized M56 Turn Buckle Self Color Carbon Steel DIN1480 Turnbuckle

Large Image :  Galvanized M56 Turn Buckle Self Color Carbon Steel DIN1480 Turnbuckle

Product Details:
Place of Origin: CHINA
Brand Name: LKY
Certification: CE, ISO
Model Number: DIN1480
Payment & Shipping Terms:
Minimum Order Quantity: 1 ton
Price: Negotiable
Packaging Details: Carton + Pallet
Delivery Time: 60 days
Payment Terms: T/T
Supply Ability: 200 tons per month

Galvanized M56 Turn Buckle Self Color Carbon Steel DIN1480 Turnbuckle

Description
Product Name: DIN1480 Turnbuckle Material: Carbon Steel
Surface: Galvanized, Self Color Size: M5 - M56
WLL: 0.2 - 23 Ton Packing: Cartong + Pallet
High Light:

Galvanized Turn Buckle

,

M56 Turn Buckle

,

Carbon Steel DIN1480 Turnbuckle

Galvanized / Self Color Carbon Steel DIN1480 Turnbuckle

Turnbuckles DIN1480:

DIN1480 turnbuckles are made by high quality carbon steel with advanced international production process. And all the samples chosen from the finished products have past the international standard. So you can absolutely believe in the quality of products. Because of the characteristics of it, it can be widely used in large construction site, large factory, shipping, bridge constraction and so on. And special specification and marks can be made according to customers requirement.

Product details:

1. Model NO.:DIN 1480

2. Material: Mild steel. Carbon steel. Malleable. Alloy steel. Stainless steel etc.

3. Type:Hook & Hook,Hook and Eye,Eye and Eye,etc

4. Usage:Marine Industry

5. Installation:External

6. Condition:New

7. Surface:Electric Galvanized, self-colored, hot dip galvanized

8. Customized: Yes

9. Size:M5-M56

10. Export Markets:Global

11. Packing:Carton with Pallet

12. Standard:ISO, CE, SGS

Specification:

Size

W.L.L.

Ton

Body Length

mm

N.W.

Kg

M5 0.2 70 0.6
M6 0.22 110 0.078
M8 0.41 110 0.16
M10 0.65 125 0.29
M12 0.9 125 0.43
M14 1.1 140 0.62
M16 1.3 170 0.92
M18 1.5 180 1.25
M20 1.7 200 1.63
M22 3.2 220 2.22
M24 3.9 255 3.00
M27 4.5 255 3.35
M30 6.2 255 4.60
M33 7.3 295 6.65
M36 8.5 295 7.68
M39 10 330 10.41
M42 12 330 12.90
M45 16 355 16.00
M48 20 355 21.00
M52 23 355 23.00
M56 23 355 24.00

Galvanized M56 Turn Buckle Self Color Carbon Steel DIN1480 Turnbuckle 0



Packing & Delivery

Galvanized M56 Turn Buckle Self Color Carbon Steel DIN1480 Turnbuckle 1

Galvanized M56 Turn Buckle Self Color Carbon Steel DIN1480 Turnbuckle 2
